Hi folks,
My idea is to fit a momentary kill switch on my 1125r next to my clutch hand (on the bars) to act as a quick shifter without using the clutch for the drag strip.
I don't know myself but it seems (with my understanding of what they do) that it may work just as well.
I don't mean air shifting, just quick shifting without using the clutch.
Anyone got any opinions on whether this will work or not?
Thanks in advance. JB

_________________
Ride Safe & Stay between the hedgerows.


Top


PostPosted: Thu Feb 27, 2020 11:21 am
Offline
User avatar

Joined: Thu May 07, 2009 11:53 am
Posts: 406
Current ride: 2006(55) XB12X
Location: Leeds
Only ridden an 1125 (CR) once.
What's it like shifting with just momentary reduction of throttle with no use of clutch? Do realise of course that you're wanting to stay on the throttle as much as possible.

_________________
Buell owners should be committed ;-)


Top


PostPosted: Thu Feb 27, 2020 12:16 pm
Offline

Joined: Wed Aug 01, 2018 7:58 pm
Posts: 1335
Current ride: Buell 1125R
delw wrote:
Only ridden an 1125 (CR) once.
What's it like shifting with just momentary reduction of throttle with no use of clutch? Do realise of course that you're wanting to stay on the throttle as much as possible.

Hi Delw,
Thanks for your response.
It will change with a drop in revs pretty easily (on the whole), but sometimes stumbles to select (or I stumble to select). As you say staying on the throttle is where I could save 10ths which over four gears is nearly half a second (which can inevitably be undone on start time) which is another problem.
I'm reckoning a momentary kill switch will bring other problems like keeping the front wheel down, but just want to try what I can before my next go.
Thanks again. JB

_________________
Ride Safe & Stay between the hedgerows.


Top


PostPosted: Thu Feb 27, 2020 3:47 pm
Offline
User avatar

Joined: Fri May 22, 2009 6:43 pm
Posts: 2596
Current ride: S1`s
Location: Llanelli South Wales
How many times will you be changing gear in quarter mile.


Top


PostPosted: Thu Feb 27, 2020 3:52 pm
Offline

Joined: Wed May 06, 2009 5:10 pm
Posts: 1987
Current ride: 99 Cyclone M2
Location: Liverpool
Air shifters like the one I have (air over air) do have an air fed ignition splitter, which kills it for a couple of milliseconds when you hit the shift button and ram on the shift lever is activated, but that happens with WOT, not sure how you would make it work using your foot to change gear, and as for launching it won't help with that.


You do not have the required permissions to view the files attached to this post.

_________________
Last year I joined a group for anti-social people
We haven't met yet.


Last edited by gusm2 on Thu Feb 27, 2020 3:56 pm, edited 1 time in total.

Top


PostPosted: Thu Feb 27, 2020 3:55 pm
Offline

Joined: Wed May 06, 2009 5:10 pm
Posts: 1987
Current ride: 99 Cyclone M2
Location: Liverpool
TOPGUMM wrote:
How many times will you be changing gear in quarter mile.

I found I was hitting 5th crossing the stripe I now have a 57t rear sprocket which helps

Picture was taken when I was using a 54t rear :oooops:

_________________
Last year I joined a group for anti-social people
We haven't met yet.


Top


PostPosted: Thu Feb 27, 2020 4:55 pm
Offline

Joined: Wed Aug 01, 2018 7:58 pm
Posts: 1335
Current ride: Buell 1125R
TOPGUMM wrote:
How many times will you be changing gear in quarter mile.


Last time I was only getting to high third, once to fourth, getting to fourth was a much better idea but with the exhaust (Remus) & ECM to suit, the power band was too far up the rev range 5 to 10 thou.
The new exhaust brings power from 2.5 to 8.5 thou which should work much better. Hoping to hit high fourth maybe even fifth next time, but I don't know to be honest, it will only be my 2nd time when I go next time.

_________________
Ride Safe & Stay between the hedgerows.


Top


PostPosted: Thu Feb 27, 2020 5:19 pm
Offline

Joined: Wed Aug 01, 2018 7:58 pm
Posts: 1335
Current ride: Buell 1125R
gusm2 wrote:
Air shifters like the one I have (air over air) do have an air fed ignition splitter, which kills it for a couple of milliseconds when you hit the shift button and ram on the shift lever is activated, but that happens with WOT, not sure how you would make it work using your foot to change gear, and as for launching it won't help with that.


Hi gusm2,
Hmmm, not really sure regarding (air over air) & ram on the shift lever or WOT means.
Yeah, launching is certainly another matter altogether.
Nothing is as easy as it would seem, that's for sure & no time for anything but getting off the line, hanging on, keeping it straight & changing gear. Sounds easy but it really, really isn't at all.
That pic's a bloody launch, (Nice bike & pic) it would've stopped my heart, re-coloured my seat or both with extras.
Hopefully see you there at some point. JB

_________________
Ride Safe & Stay between the hedgerows.


Top


PostPosted: Thu Feb 27, 2020 7:10 pm
Offline
User avatar

Joined: Fri Mar 11, 2016 7:28 pm
Posts: 997
Current ride: 1125r XB12X
Location: South
https://www.healtech-electronics.com/products/iqse/


Top


PostPosted: Thu Feb 27, 2020 7:40 pm
Offline
User avatar

Joined: Wed May 06, 2009 1:43 pm
Posts: 5801
Current ride: The wife
Location: Cofa's tree
That pic has got to be a contender for next year's calendar

_________________
I hate being strapped for cash....but it pays the bills


Top


PostPosted: Thu Feb 27, 2020 8:00 pm
Offline

Joined: Wed May 06, 2009 5:10 pm
Posts: 1987
Current ride: 99 Cyclone M2
Location: Liverpool
Hi, WOT -wide open throttle, air over air as opposed to electric over air is how the pneumatic ram connected to the shift lever is controlled.
Mine has pipes from the air tank to the button on the bars that go to the ignition splitter which is pressure operated.
The other has a button with wires going to an electronic splitter.
So basically I watch the shift light which is set at 6300 rpm and press the button each time it lights
I've got a slow motion video that you can see the gear change happen with both feet off the pegs, I'll see if I can upload it
:yup:

_________________
Last year I joined a group for anti-social people
We haven't met yet.


Top


PostPosted: Thu Feb 27, 2020 10:25 pm
Offline
User avatar

Joined: Tue May 05, 2009 8:00 pm
Posts: 10148
Current ride: X1 2001 White Riot
Location: southampton
Finmows wrote:
That pic has got to be a contender for next year's calendar


:yup: :yup:

_________________
Obey the principles without being bound by them.
Bruce Lee


Top


PostPosted: Fri Feb 28, 2020 10:27 am
Offline
User avatar

Joined: Thu May 07, 2009 11:53 am
Posts: 406
Current ride: 2006(55) XB12X
Location: Leeds
Kiwi wrote:
https://www.healtech-electronics.com/products/iqse/


Do those ladies provide personal technical support?

_________________
Buell owners should be committed ;-)


Top


PostPosted: Fri Feb 28, 2020 11:28 am
Offline

Joined: Wed Aug 01, 2018 7:58 pm
Posts: 1335
Current ride: Buell 1125R
Kiwi wrote:
https://www.healtech-electronics.com/products/iqse/


Thanks Kiwi.

_________________
Ride Safe & Stay between the hedgerows.


Top


PostPosted: Fri Feb 28, 2020 11:54 am
Offline

Joined: Wed Aug 01, 2018 7:58 pm
Posts: 1335
Current ride: Buell 1125R
gusm2 wrote:
Hi, WOT -wide open throttle, air over air as opposed to electric over air is how the pneumatic ram connected to the shift lever is controlled.
Mine has pipes from the air tank to the button on the bars that go to the ignition splitter which is pressure operated.
The other has a button with wires going to an electronic splitter.
So basically I watch the shift light which is set at 6300 rpm and press the button each time it lights
I've got a slow motion video that you can see the gear change happen with both feet off the pegs, I'll see if I can upload it
:yup:


Thanks gusm2.
I get it now, saw a variety when I was down there on other peoples bikes, heard compressors running etc. Thanks for sharing the different types for me. :yup:
I think what I spend & type I get will depend on my next runs after I can see what difference the exhaust makes over the 1/4 mile and if my times spur me on to this stage of upgrade.
Got to say though, watching for a light to change gear seems a lot easier than trying to get it right manually as getting the millisecond timing correctly with a simple switch are minimal. So thanks for clearing that up also (without calling me a dick). :yup:
The 13.5 second runs are like the quickest & the longest time ever, at the same time. :? I think that statement may be an oxymoron in grammar terms but it's correct I think. :?
Littlebutquick did 10.6 with manual clutch & gearing with a T/H1 & ECM, if I could get anywhere under 13.5 with the T/H2 & ECM I'll be happy for the moment, unfortunately I know that won't last.
Thanks again. JB
