 Post subject: Oil filter tip
PostPosted: 07 Jun 2020 17:00
Offline

Joined: 29 May 2020 22:52
Posts: 12
Current ride: Firebolt XB12R
Serviced the Buell today. Anyone else do this to protect against the filter coming loose. ImageB94A5141-C134-449B-85CA-E95A1015AE6C by Russell Duncan, on Flickr

It looks a bit like the Jubilee clip buckle is fouling the oil pipe but I can assert that it isn’t ImageC6E89BAC-7C5F-4303-A833-2EF7BD457F5C by Russell Duncan, on Flickr

_________________
The older I get, the faster I was.


Top
 Post subject: Re: Oil filter tip
PostPosted: 07 Jun 2020 18:19
Offline

Joined: 06 May 2009 17:10
Posts: 2484
Current ride: 99 Cyclone M2
Location: Liverpool
I've never had that problem

_________________
Last year I joined a group for anti-social people
We haven't met yet.


Top
 Post subject: Re: Oil filter tip
PostPosted: 07 Jun 2020 18:33
Offline
Site Admin
User avatar

Joined: 15 Apr 2009 17:17
Posts: 8632
Location: Manchester
Nor has anyone else as far as I'm aware :?

_________________
Mithered ta death.
92 MB
96 S2T
98 S1W
00 M2
01 X1
03 P3
10 CR


Top
 Post subject: Re: Oil filter tip
PostPosted: 07 Jun 2020 18:42
Offline
User avatar

Joined: 06 May 2009 14:02
Posts: 889
Usually the opposite, hard to get off. The rubber grips like hell once warmed

_________________
2017 KTM 690 Duke
2001 M2
2019 Street Triple RS
2004 Monster S4R
Wilier La Triestina


Top
 Post subject: Re: Oil filter tip
PostPosted: 07 Jun 2020 19:14
Offline
User avatar

Joined: 07 Nov 2011 18:10
Posts: 4061
Current ride: Buell ulysses
Location: Telford
Tick
:yt: its in the ACU handbook for road racing " Sump plug, oil filters, Ignition pickup covers and Clutch centre covers should all be lock wired or lock plated."
IIRC in the early days of the Suzuki GSXR racing they lost a few filters , high rev's, high flow rate ,cooling as well as lube or the result of incorrectly fitted , but rules soon appeared to ensure mechanically locked .


Attachments:
filter.jpg [ 105.03 KiB | Viewed 1539 times ]

_________________
Buell Ulysses XB12X 06/08
Top
 Post subject: Re: Oil filter tip
PostPosted: 08 Jun 2020 19:01
Offline
User avatar

Joined: 06 May 2009 17:28
Posts: 7256
Current ride: 1991 RS1200 westwind
Never ever had an oil filter come loose on any vehicle , the only. time I've heard it happen was with aftermarket filters that would screw on to the engine BUT were actually the wrong thread.

_________________
2001 X1 2009 1125CR 2006 Uly X3 2010 Uly a fully Maz'd S1 and a 1991 RS1200 Westwind.


Top
 Post subject: Re: Oil filter tip
PostPosted: 09 Jun 2020 11:21
Offline
Moderator
User avatar

Joined: 15 Apr 2009 17:25
Posts: 11771
Location: Oswestry
I had the filter on my Ducati 1198 come loose after taking part in the Ramsey Sprint. I hate worm drive clips because they can be a bit 'pinchy', so made my own clamp. Mine is the only instance I know of this happening.

_________________
If your dreams don't scare you, they are not big enough.


Top
 Post subject: Re: Oil filter tip
PostPosted: 09 Jun 2020 13:41
Offline
User avatar

Joined: 29 Apr 2009 19:27
Posts: 927
Adam wrote:
I had the filter on my Ducati 1198 come loose after taking part in the Ramsey Sprint. I hate worm drive clips because they can be a bit 'pinchy', so made my own clamp. Mine is the only instance I know of this happening.

So - You were either a victim of Murphy's Law (what can go wrong etc...) or the Spanish Inquisition (nobody expects etc.....).

_________________
Try doing this to yer fueller...........


Top
 Post subject: Re: Oil filter tip
PostPosted: 09 Jun 2020 17:48
Offline

Joined: 29 May 2020 22:52
Posts: 12
Current ride: Firebolt XB12R
Totally get what folks are saying about effectively fixing a problem that doesn't exist. My take is that the bike is a total unknown to me so far and this is a 50 pence insurance policy against disaster. I've always done this since the days when I used to prep race bikes. (Longer ago than I care to remember) Maybe not necessary but it's reassuring.

_________________
The older I get, the faster I was.


Top
 Post subject: Re: Oil filter tip
PostPosted: 10 Jun 2020 07:01
Offline
User avatar

Joined: 07 Nov 2011 18:10
Posts: 4061
Current ride: Buell ulysses
Location: Telford
:yt: I also do the oil drain plug as well ( lockwire) :yup:

_________________
Buell Ulysses XB12X 06/08


Top
 Post subject: Re: Oil filter tip
PostPosted: 10 Jun 2020 08:31
Offline

Joined: 11 Dec 2009 15:36
Posts: 72
Current ride: 09 XB12XT, Guzzi V11
Location: Cheshire
The jubilee clip idea is recommended on Guzzi V11s like I own. The filter is inside the sump and has been known to unscrew so no oil dripping on the floor to warn you, the first sign would be loss of oil pressure and a scrap engine.


Top
 Post subject: Re: Oil filter tip
PostPosted: 10 Jun 2020 11:13
Offline

Joined: 29 May 2020 22:52
Posts: 12
Current ride: Firebolt XB12R
barney wrote:
:yt: I also do the oil drain plug as well ( lockwire) :yup:

I might do that yet, there's NFW I'm tightening it to 40nm like the manual says, that's for sure. (Surely that's a mis-print?). The OCD is strong in this one so i might buy a new drain plug and wire that one. I've used the Loctite 565 that the manual suggests but it's not a product i've ever used before.

_________________
The older I get, the faster I was.


Top
 Post subject: Re: Oil filter tip
PostPosted: 10 Jun 2020 11:15
Offline

Joined: 29 May 2020 22:52
Posts: 12
Current ride: Firebolt XB12R
johne wrote:
The jubilee clip idea is recommended on Guzzi V11s like I own. The filter is inside the sump and has been known to unscrew so no oil dripping on the floor to warn you, the first sign would be loss of oil pressure and a scrap engine.


That's a handy place to keep it! You must like your big V-Twins. Had a Guzzi 1000SP before. A friend has it now. Bags of character that thing.

_________________
The older I get, the faster I was.


Top
 Post subject: Re: Oil filter tip
PostPosted: 10 Jun 2020 12:51
Offline
User avatar

Joined: 07 Nov 2011 18:10
Posts: 4061
Current ride: Buell ulysses
Location: Telford
Tick wrote:
barney wrote:
:yt: I also do the oil drain plug as well ( lockwire) :yup:

I might do that yet, there's NFW I'm tightening it to 40nm like the manual says, that's for sure. (Surely that's a mis-print?).

:yt: new o ring and nip it up ,then lockwire :yup: you sound like you've been around bikes long enough to know when things are tight . big lumpy twins do tend to vibrate and things fall off , I like Loctite 222 , just a low strength screw lock on fasteners .

_________________
Buell Ulysses XB12X 06/08


Top
