I seem to have a rattle/knocking from the primary on my Uly.

I only noticed this the other week and so adjusted the primary chain

However it's still there. I'll check my adjustment again, but otherwise any idea what this rattle/knocking might be?

Watch the video and you'll see the noise if definitely from the primary side

_________________
"Because it's awesome" is always a good enough excuse

http://www.eugenereisch.com

Any ideas anyone?

_________________
"Because it's awesome" is always a good enough excuse

http://www.eugenereisch.com

Can't access the vid here ....could it be a loose crank nut ??? need to get it checked asap if it is before it destroys the crank splines .

_________________
2001 X1 2009 1125CR 2006 Uly X3 2010 Uly a fully Maz'd S1 and a 1991 RS1200 Westwind.

recheck the chain tension

_________________
Feros Ferio

That I can check...

_________________
"Because it's awesome" is always a good enough excuse

http://www.eugenereisch.com

That I dont even understand.

Is it something in can check with the help of a service manual... Or step away, stop riding and seek immediate professional service?

_________________
"Because it's awesome" is always a good enough excuse

http://www.eugenereisch.com

Hmm... ok, so primary cover off, lock the sprockets (somehow) and tighten the nut to new torque settings, with Locktite... in a nutshell...

That might be within my personal 'do-able' range

I assume I'l need a new gasket when I remove the primary cover.

_________________
"Because it's awesome" is always a good enough excuse

http://www.eugenereisch.com

The sprocket locking tool needs to be a softer material than the sprockets ie brass or aluminium

_________________
2001 X1 2009 1125CR 2006 Uly X3 2010 Uly a fully Maz'd S1 and a 1991 RS1200 Westwind.

I reckon that's a loose crank nut ?.......you will need a new nut and industrial strength locktite (even though the new nut will be patchlocked) and a mega torque wrench.
A home made paper gasket wont last 5 mins........these gaskets are laminated aluminium for a reason

_________________
Mithered ta death.
92 MB
96 S2T
98 S1W
00 M2
01 X1
03 P3
10 CR

So I'm doing this bit then...

See Figure 6-34. Install the engine sprocket nut.
a. Install SPROCKET LOCKING LINK (Part No. HD-38362).

b. Apply two or three drops of LOCTITE 272 (red) onto threads of sprocket shaft.

c. Install engine sprocket nut. Tighten to 190-210 ft-lbs (257.6-284.7 Nm).


Should/can I buy the SPROCKET LOCKING LINK or any handy DIY alternatives?

_________________
"Because it's awesome" is always a good enough excuse

http://www.eugenereisch.com

Big brass door hinge can be used to lock the transmission. Yourguitarhero posted a how to for something behind the primary cover. It shows the hinge in action...

_________________
08 Specialized Langster

hmmm... I think i'd best not mess about with that which i don't really understand

A trip to Warrs methinks.

_________________
"Because it's awesome" is always a good enough excuse

http://www.eugenereisch.com

.......and the revised torque figure is 240lbft from memory.

_________________
Mithered ta death.
92 MB
96 S2T
98 S1W
00 M2
01 X1
03 P3
10 CR

Don't ride it until it's sorted. Triumph Saints used to suffer from that with the Police spec rotor, but once you heard the noise, it was too late, your crank bearings were history.
If you've not got a torque wrench that goes that high, get a steel bar 240' long and a 1lb weight

_________________
If your dreams don't scare you, they are not big enough.

A strip of 6x25mm ali will do to lock up your sprockets.
